BEYONDTECH LC to LC Fiber Patch Cable Single Mode Duplex - 20m (65.6ft) - 9/125um, Compatible with OS1 - OS2, LSZH PureOptics Cable Series
By Amazon
SAR 173.00
Buy from providerThe following is extracted using AI so it may be inaccurate
| Attribute | Value | Help |
|---|---|---|
| Mode | Duplex | |
| Type | Fiber Patch Cable | |
| Brand | Beyondtech | |
| Color | Yellow | |
| Length | 20m | |
| Diameter | 3.00mm | |
| Material | LSZH | |
| Standard | OS1 | |
| Length ft | 65.6ft | |
| Compliance | TIA/EIA 492AAAA, IEC60793-2-10 A1b, RoHS | |
| Fiber type | Single Mode | |
| Applications | Fast Ethernet, Fiber Channel, Gigabit Ethernet, Data center, Premises, Educational, LAN, SAN, 10GBASE-L, 10GBASE-E, 1000BASE-LX, ATM | |
| Core diameter | 9/125um | |
| Connection type | LC to LC |
About this item
- Beyondtech high-quality LC to LC Fiber Patch Cable Single mode 9/125 OS1 fiber is specially designed for fast Ethernet, Fiber Channel, Gigabit Ethernet Speeds, data center, premises, educational, LAN, SAN, commercial, 10GBASE-L (1310 nm), 10GBASE-E (1550 nm), 1000BASE-LX (1300 nm) and Asynchronous Transfer Mode (ATM) applications. It supports video, data and voice services.
- This fiber OS1 LC LC Fiber Patch Cord conforms with TIA/EIA 492AAAA and IEC60793-2-10 A1b standards and complies with RoHS specifications.
- This SM fiber has an yellow color jacket with a 3.00mm diameter. OS1 cables have a 0.25 dB/km attenuation at 1550 nm and 0.35 dB/km at 1310 nm.
- This LC to LC Single mode Duplex OS1 fiber patch cords operate at -20ºC to +70ºC and have a minimum installation bending radius of 5.0 cm and a minimum long term bending radius of 3 cm.
- OS1 patch cords allow for connections between patching panels and network and server equipment. OS1 9/125 patch cords are commonly used in passive applications (GPON, FTTX and LANs) - LC duplex connectors are joined with a plastic clip, easy to remove in case you need to separate the connectors.
